1 x PS/2 keyboard/mouse port

1 x HDMI port

2 x DisplayPorts

1 x USB 3.2 Gen 2 Type-A port (red)

3 x USB 3.2 Gen 1 ports

4 x USB 2.0/1.1 ports

2 x RJ-45 ports

1 x optical S/PDIF Out connector

5 x audio jacks

1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x 4-pin ATX 12V power connector

1 x PMBUS (Power Information Detection) header

2 x M.2 Socket 3 connectors

10 x SATA 6Gb/s connectors

2 x SATA DOM power connectors

2 x SATA detection headers

1 x CPU fan header

1 x water cooling CPU fan header

2 x system fan headers

2 x system fan/water cooling pump headers

1 x front panel header

1 x front panel audio header

1 x USB 3.2 Gen 1 port (USB30_OB)

1 x USB Type-C™ header, with USB 3.2 Gen 2 support

1 x USB 3.2 Gen 1 header

1 x USB 2.0/1.1 header

2 x Thunderbolt™ add-in card connectors

1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)

2 x serial port headers

2 x temperature sensor headers

1 x power button

1 x reset button

1 x Clear CMOS button

1 x Clear CMOS jumper

1 x Q-Flash Plus button
